1 / 3Horizontal Axis Wind Turbines
Aervon 5 kW Horizontal Axis Wind Turbine
This horizontal-axis model is suited to sites where wind resource, tower placement and electrical integration support a conventional rotor layout. All performance decisions require site assessment.
off-gridhybrid
Technical specifications
- Rated power
- 5 kW
- Max power
- 5.5 kW
- Blade length
- 1.95 m
- Wheel diameter
- 3.99 m
- Rated voltage
- 96 V to 380 V
- Start-up speed
- 2.5 m/s
- Rated speed
- 12 m/s
- Cut-in speed
- 3 m/s
- Survival speed
- 45 m/s
Need a parameter that is not listed? Contact Aervon for the complete technical specification.
Suitable applications
Farms
Commercial land
Industrial support loads
Hybrid systems
Brochure access
Request the latest technical sheet and our team will share the appropriate document for your project.
