Aervon 2 kW Vertical Axis Wind Turbine
This Aervon vertical-axis wind turbine uses a maglev permanent magnet generator and low start-up speed. Final selection must be based on site wind conditions, structure, electrical load and controller/inverter design.
off-gridhybrid
Technical specifications
- Rated power
- 2 kW
- Blade length
- 1.1 m
- Wheel diameter
- 0.52 m
- Rated voltage
- 12 V to 48 V
- Start-up speed
- 1.5 m/s
- Rated wind speed
- 12 m/s
- Cut-in speed
- 4.0 m/s
- Survival wind speed
- 45 m/s
- Generator type
- Coreless disc type maglev levitation permanent magnet generator
- Protection level
- IP54
Need a parameter that is not listed? Contact Aervon for the complete technical specification.
Suitable applications
Homes
Farms
Small commercial
Remote sites
Brochure access
Request the latest technical sheet and our team will share the appropriate document for your project.
